Industrial Vibrators

OLI Electric Vibrating Motors can generate a centrifugal force up to 26,000 kg and are available in multiple voltages. For this reason, the range of OLI industrial Vibrators can be used in numerous sectors of application – from construction to the mining industry, from the foodstuff industry to recycling – in every country around the world.

The motor casings, the support flanges and the shafts were designed according to FEMA criteria and are assembled using top quality aluminium alloys, cast iron and steel alloys, to allow the Vibrator to deal with high intensity applications and guarantee safe operations in every condition.

The windings are impregnated with Class F insulating materials, adjustable eccentric masses allow easy calibration of the maximum centrifugal force generated by the motor. Operating temperature -10°C / +40°C

Specifications

MVE Standard Range: Centrifugal force: 20 ~ 26,000 kg, Voltages 12 and 24 VDC, from 220 to 690VAC, class F, 2, 4, 6, 8 poles, 3 phase 2 pole 1 phase
MVE-DC Direct current: Centrifugal force from 50 to 1500 kg, DC motor 3000 RPM 12V-24VPower from 80 to 520
MVE-Exe Increased Safety Range: Centrifugal force 50 ~ 10000 kg, Voltages from 220 to 690VAC, class F, 2, 4, 6, 8 poles, 3 phase
MVE-F Flanged Vibrators: Centrifugal force 200 ~ 3500 kg, class F, 2, 4, 6 pole 3 phase
MVE-FD Flanged Drive: Centrifugal force 4500 – 25000 kg; 6 & 8 poles from 220 to 690V
MVE-HF – External high frequency electric vibrating motors: S1 continuous, Multi voltage 3phase 42V – 3phase 230/400V (* tolerance ± 10%), Fixed frequency 50Hz and 200Hz, Variable frequency 0 ÷ 100Hz, Maximum noise: 85 dB (A) at 1 m distance
MVE-SS Stainless Steel: Centrifugal force 105 ~ 500 kg, 2, 4, 6, 8 poles 3 phase
MVE-Milling Grain Processing: Centrifugal force 500 – 1400 kg; 6, 8, 1 and 12 poles from 220 to 575V
MVE-MICRO: Centrifugal force 3 ~ 65 kg, 6, 8, 10 & 12 poles single phase and three phase
MVE-SV Screen Vibrators: Centrifugal force 3500 – 8000 kg,4 poles from 220 to 575V
OWC – Rubber Oscillating Suspension: OWC 7 sizes available in the OWSNE model and 6 sizes available
VISAM Electric Motovibrators Range: Centrifugal Force (S1), Range 2, 4, 6, 8, 10, 12 poles & specials Power supply 3 phase from 42 up to 700 V at 50 and 60 Hz, 1 phase from 110 up to 240 V at 50 and 60 Hz.
MVE-Exd Explosion-Proof: Centrifugal force:800 ~ 5500 kg, class F , 2, 4, 6, 8 poles 3phase
